6ES7135-6FB00-0BA1 SIEMENS

Product Dimensions：

Potential separation digital inputs

● between the channels No

● between the channels and backplane bus Yes

● Between the channels and load voltage L+ No

Permissible potential difference

between M internally and the inputs 75 V DC/60 V AC

Isolation

Isolation tested with 500 V DC

Standards, approvals, certificates

CE mark Yes

Highest safety class achievable in safety mode

● acc. to EN 954 Cat. 3 (single-channel), Cat. 4 (two-channel)

● Performance level according to ISO 13849-1 e

● SIL acc. to IEC 61508 SIL 2 (single-channel), SIL 3 (two-channel)

Ambient conditions

Ambient temperature during operation

● min. -25 °C; = Tmin

● max. 60 °C; = Tmax

Extended ambient conditions

● relative to ambient temperature-atmospheric

pressure-installation altitude

Tmin ... Tmax at 1080 hPa ... 795 hPa (-1000 m ... +2000 m)

Relative humidity

— With condensation, tested in accordance

with IEC 60068-2-38, max.

100 %; RH incl. condensation/frost (no commissioning under

condensation conditions)

Resistance

— against biologically active substances /

conformity with EN 60721-3-3

Yes; Class 3B2 mold, fungus and dry rot spores (with the

exception of fauna); Class 3B3 on request

— against chemically active substances /

conformity with EN 60721-3-3

Yes; Class 3C4 (RH < 75%) incl. salt spray according to EN

60068-2-52 (degree of severity 3). The supplied connector covers

must remain on the unused interfaces during operation!

— against mechanically active substances /

conformity with EN 60721-3-3

Yes; Class 3S4 incl. sand, dust. The supplied connector covers

must remain on the unused interfaces during operation!

We have the same series of models in stock.  If you don't find the model you need, please contact us and we will provide you with an official quotation！

SIEMENS6SE6440-2UD13-7AA1

SIEMENS6SL3224-0BE37-5AA0

SIEMENS6DD1684-0BC0

SIEMENS6DD1684-0AH0

SIEMENS6AV6542-0CA10-0AX0

SIEMENS3RT1044-1AG20

SIEMENS6AV6647-0AH11-3AX0

SIEMENS3RT2017-1AF01

SIEMENS6ES7321-1CH20-0AA0

SIEMENS6ES7331-7HF01-0AB0

SIEMENS6ES7195-7HA00-0XA0

SIEMENS6SE70386GL841JA1

SIEMENSGB14048.5

SIEMENS6ES7131-4BD01-0AA0

SIEMENS3TB4817-OA

SIEMENS3TB46 17-OA

SIEMENS3UA5840-2F

SIEMENS6ES74145HM060AB0

SIEMENS5SX21C0.5

SIEMENS6AV6648-0CC11-3AX0

SIEMENS6FX5002-2DC10-1FA0

SIEMENS6EP1333-3BA00

SIEMENS6BK1620-0AA00-0AA0

Colour：new                                Warranty: 12 months

Lead Time：3-day working day    Price: Please contact us

Shipping Port: Xiamen, China       Payment:T/T

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service
