3RV2011-1GA10 SIEMENS

Product Dimensions：

Short-circuit protection

Design of the fuse link

● for short-circuit protection of the main circuit

— with type of coordination 1 required gG NH 3NA, DIAZED 5SB, NEOZED 5SE: 100 A

— with type of assignment 2 required gG NH 3NA, DIAZED 5SB, NEOZED 5SE: 35 A

● for short-circuit protection of the auxiliary switch

required

fuse gG: 10 A

Installation/ mounting/ dimensions

Mounting position +/-180° rotation possible on vertical mounting surface; can be

tilted forward and backward by +/- 22.5° on vertical mounting

surface

Mounting type screw and snap-on mounting onto 35 mm standard mounting rail

according to DIN EN 60715

● Side-by-side mounting Yes

Height 85 mm

Width 45 mm

Depth 107 mm

Required spacing

● for grounded parts

— at the side 6 mm

● for live parts

— at the side 6 mm
