LADN20 SCHNEIDER

Product Dimensions：

Range of product Modicon Quantum automation platform

Product or component type Input/output analog module

Type of filter Single pole low pass - 3 dB at 21 Hz +/- 20 % input circuit

I/O modularity 6 channels

Addressing requirement 5 input words

2 output words

Analogue input number 4

Analogue input type Bipolar current +/- 20 mA 15 bits DC

Bipolar voltage +/- 10 V 16 bits DC

Bipolar voltage +/- 5 V 15 bits DC

Unipolar current 0...20 mA 15 bits DC

Unipolar offset current 4...20 mA 14 bits DC

Unipolar offset voltage 1...5 V 14 bits DC

Unipolar voltage 0...10 V 16 bits DC

Unipolar voltage 0...5 V 15 bits DC

Absolute maximum input +/- 25 mA current

+/- 50 V voltage

Input impedance > 10 MOhm voltage

> 250 Ohm current

Offset +/- 0.0014 % of full scale maximum/°C 0...60 °C input circuit

Gain shift +/- 0.002 of full scale maximum 0...60 °C input circuit

Common mode rejection > 80 dB 50/60 Hz input circuit

Analogue output number 2

Analogue output range 4...20 mA

Analogue output resolution 12 bits

Loop voltage 0...60 V DC with external resistance output circuit

7...30 V DC output circuit

Voltage drop 30 V DC 20 mA

Setting time 900 µs to +/- 0.1 % of the final value output circuit

We have the same series of models in stock.  If you don't find the model you need, please contact us and we will provide you with an official quotation！

SCHNEIDER 140CRA21220

SCHNEIDER BMXDAI1604

SCHNEIDER 140XTS00200

SCHNEIDER 140XBP01600

SCHNEIDER LMC058

SCHNEIDER TM2ALM3LT

SCHNEIDER HMIGXO3501

SCHNEIDER CAD326BD

SCHNEIDER NS250L (160 A)

SCHNEIDER 750XBXH-24D

SCHNEIDER ATV28HU18N4

SCHNEIDER XC1-ZA2

SCHNEIDER LC1-D09F7

SCHNEIDER LC1D18E7

SCHNEIDER LC1-D09E7

SCHNEIDER LC1-D12E7

SCHNEIDER LC1-D32E7

SCHNEIDER XTCE025C10TD

SCHNEIDER XS530BSDBL2

SCHNEIDER XS8C4A4PCG13

SCHNEIDER LCID65F7

SCHNEIDER TSXP571634M

SCHNEIDER XSAV11373

SCHNEIDER ATV610U55N4

SCHNEIDER BMXDDO1602

SCHNEIDER BMXDDO3202K

Colour：new                             Warranty: 12 months

Lead Time：3-day working day      Price: Please contact us

Shipping Port: Xiamen, China       Payment:T/T

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service
