3DM2-WRDUW SCHNEIDER

3DM2-WRDUW SCHNEIDER Central control module

Brand:SCHNEIDER           Model number:3DM2-WRDUW

Country of origin: France             Product weight:0.55kg

HS code:853710119

Product Details:

Product Dimensions

Processor running (RUN) 1 LED green)

Processor or system fault (ERR) 1 LED red)

I/O module fault (I/O) 1 LED red)

Download in progress (DL) 1 LED green)

Memory card or CPU flash fault (BACKUP) 1 LED red)

ETH MS (Ethernet port configuration status) 1 LED green/red)

Eth NS (Ethernet network status) 1 LED green/red)

Peer processor running (REMOTE RUN) 1 LED green)

Processor ID set to A (A) 1 LED green)

Processor ID set to B (B) 1 LED green)

Processor acting as Primary (PRIM) 1 LED green)

Processor acting as Standby (STBY) 1 LED green)

I/O values overrided by user (FORCED IO) 1 LED green)

Hot standby link status (Hsby Diag) 1 LED green)

a: additional space below the rack to accommodate the height of the CPU. For an X Bus rack, the value is 30.9 mm (1.217 in.); for an

Ethernet rack, the value is 29.49 mm (1.161 in.).

b: the height of the rack. For an X Bus rack, the height is 103.7 mm (4.083 in.); for an Ethernet rack, the height is 105.11 mm (4.138 in.).

c: the height of the main local rack, 134.6 mm (5.299 in.)

a: enclosure depth: 135 mm (5.315 in.)

b: wiring + module depth: > 146 mm (5.748 in.)

c: wiring + module + DIN rail depth: > 156 mm (6.142 in.)

d: rack height: for an X Bus rack 103.7 mm (4.083 in.); for an Ethernet rack, 105.11 mm (4.138 in.)

e: module height: 134.6 mm (5.299 in.)


We have the same series of models in stock.  If you don't find the model you need, please contact us and we will provide you with an official quotation!
