F4-MAS-MB AutomationDirect

F4-MAS-MB AutomationDirect AutomationDirect Input module

Brand：AutomationDirect Model number：F4-MAS-MB

Country of origin: U.S. Product weight：0.55kg

HS code：8517623990

Inquire Now Next Product

Product Details：

Product Dimensions：

Follow these best practices to be sure that your migration is successful.

• Upload and save the PowerFlex 700AFE parameters via Connected

Components Workbench™, Studio 5000 Logix Designer®, or

DriveExecutive™ software. If you cannot connect to the drive online,

manually record the parameter values.

• Record and label all power, digital, and analog I/O control wiring.

• Upload and save any network files and programmable logic controller (PLC) programs.

Before proceeding with detailed migration guidelines, see Table 1 on page 7 to verify that you can migrate your PowerFlex 700AFE bus supply.

You must consider the hardware and control differences between the

PowerFlex 700AFE and PowerFlex 755TM bus supplies. This chapter

describes some of the primary differences. Additional chapters will provide indepth comparisons.

A common DC bus drive system is a complex electrical and mechanical system that can be composed of many different power devices, such as DC input common bus inverter, capacitor banks, bus conditioners, and common mode filters. Because these drive systems are custom designed, it is important to review the existing inverter and other equipment that will be connected to the DC bus to confirm whether the equipment is compatible with the new

PowerFlex 755TM bus supply. Some devices are not compatible and must be substituted, removed completely, or circuits modified for use with the PowerFlex 755TM bus supply.

Custom enclosures and hardware configurations using Bulletin 2100 MCC enclosures were created by Rockwell Automation drive systems and many system integrators. Because of the many variations that are possible with IP00 open type equipment, this document does not cover custom engineered AFE migrations. Contact an Authorized Rockwell Automation Distributor specialist, Solution Partner, Recognized System Integrator, or a Rockwell Automation account manager to discuss engineered solutions for these AFE migrations.

F4-04DA-1 AutomationDirect

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
