1C31177G03 Emerson Processor module

Retreat is a feature that occurs after Seating. It is highly programmable.

When the target position is less than seatLimit, the RSR goes into a seating mode.






Product Details:

1C31177G03 Emerson Processor module

Brand:Emerson                                   Model number1C31177G03

Country of origin: United States          Product weight:  1.42kg

HS code:8517623990

Product Dimensions:

Seating and BackSeating are similar functions, with the exception that Seating closes the

valve, and BackSeating opens it. Therefore, only Seating is described.

Retreat is an anti-windup function. It is important to remember that when the RSR servo

output is near 0 volts, the valve is stationary. When the servo output moves away from the

midpoint, the valve moves to the desired position, and the servo output goes back to near

0 volts.

Retreat is a feature that occurs after Seating. It is highly programmable.

When the target position is less than seatLimit, the RSR goes into a seating mode. In this

mode the RSR wants to close the valve as fast as possible. It accomplishes this by driving

the output hard to the rail in the direction of valve closure.

Retreat occurs after a timer has expired (retreatHoldT), and once the valve position is close

to where the RSR wants it to be (ABS|Target-Feedback| < posErrorRetreat). When a valve

retreats, the servo output goes from the rail to a programmed value (exitSeatVal) at a

predefined rate (retreatRate).
