PHIDPS25IBLCSP EATON

PHIDPS25IBLCSP EATON Output Module

Brand：EATON Model number：PHIDPS25IBLCSP

Country of origin: the States Product weight：0.55kg

HS code：8538900000

Product Details：

Product Dimensions：

Eaton output modules are integral components within industrial automation systems, designed to deliver electrical signals that control various output devices. These modules act as the interface between a control system (like a PLC) and actuators, enabling the execution of automated processes.

Product Details

Functionality:

Relays
Solenoids
Motor starters
Valves
Indicators
Output modules transmit electrical signals to activate devices such as:
They translate control signals from the PLC into the appropriate electrical signals needed to drive these output devices.

Types:

Digital Output Modules: Provide on/off signals for controlling discrete devices.
Relay Output Modules: Use electromechanical relays to switch higher current loads.
Transistor Output Modules: Employ transistors for fast switching of DC loads.
Analog Output Modules: Generate continuous voltage or current signals to control analog devices.
Eaton offers a range of output modules, including:

Key Features:

Robust construction for industrial environments.
Various output voltage and current ratings.
Isolation to protect the control system from field wiring issues.
LED indicators for output status.
Compatibility with various industrial communication protocols.

Product Parameters

Voltage Ratings:

Output voltage (e.g., 24V DC, 120V AC, 230V AC).

Current Ratings:

Maximum output current per channel and per module.

Number of Channels:

Number of individual output points per module.

Output Type:

Relay, transistor (PNP, NPN), analog (voltage, current).

Switching Speed:

For transistor outputs, the speed at which the output can switch on and off.

Isolation Voltage:

The voltage rating for isolation between the field wiring and the control system.

Operating Temperature:

The range of temperatures the module can withstand.

Environmental Protection:

IP rating for dust and moisture resistance.

Product Advantages

Reliability:

Eaton output modules are designed for reliable operation in industrial settings.

Flexibility:

A variety of module types and ratings to match application needs.

Safety:

Isolation features enhance safety and protect equipment.

Diagnostics:

LED indicators and diagnostic capabilities simplify troubleshooting.

Compatibility:

Designed to integrate with Eaton and other control systems.

Important Considerations

Application Requirements:

Select modules that match the voltage, current, and output type of the devices being controlled.

Wiring and Installation:

Follow proper wiring and installation guidelines.

Environmental Conditions:

Ensure modules are installed within their rated temperature and humidity ranges.

Load Characteristics:

Consider the type of load being controlled (inductive, resistive) and select modules with appropriate ratings.

Safety Standards:

Ensure that the selected modules comply with all relevant safety standards.

Product Applications

Industrial Automation:

Controlling motors, valves, and actuators in manufacturing and process control.

Robotics:

Activating robotic arms and end effectors.

Material Handling:

Controlling conveyors and sorting systems.

Packaging Machinery:

Activating various devices in packaging lines.

Building Automation:

HVAC systems, and lighting control.
