EHD2100225A EATON

EHD2100225A EATON Termination Unit

Brand：EATON Model number：EHD2100225A

Country of origin: the States Product weight：0.55kg

HS code：8538900000

Product Details：

Product Dimensions：

Eaton offers a variety of termination units designed to provide secure and organized connection points for electrical wiring in various applications. These units facilitate the connection of conductors to equipment, ensuring reliable power distribution and control signal transmission. The specific features and types of termination units can vary significantly based on their intended use.

Product Details

Functionality:

Termination units provide a structured and safe way to connect and disconnect wires.
They often include features for strain relief, wire management, and protection of the connection points.
Some units may offer additional functionalities like fusing or signal conditioning.

Types (Examples):

Terminal Blocks: A fundamental type of termination unit offering screw, spring-clamp, or push-in connections for wires. Available in various pole configurations and current/voltage ratings.
Wiring Duct/Raceway: While not termination units themselves, they are essential for organizing and protecting the wiring leading to termination points.
Power Distribution Blocks: Used for distributing power from a main source to multiple circuits, often with integrated fusing options.
Grounding Blocks: Specifically designed for creating reliable ground connections.
Interface Modules: These units provide a transition between different wiring types or signal levels, often incorporating terminal blocks for field wiring.
Fuse Blocks: Termination points that also hold fuses for circuit protection.
Busbar Systems: Offer a robust and flexible solution for power distribution, with tap-off points for connections.

Key Features (Vary by Type):

Multiple connection methods (screw, spring, push-in).
Range of wire gauges accommodated.
Current and voltage ratings.
Number of poles or connection points.
Insulation materials.
Mounting options (DIN rail, panel mount).
Integrated components like fuses, surge protection, or signal conditioning.
Clear labeling options.
Safety features like touch-safe designs.

Product Parameters

Voltage Rating: The maximum voltage the termination unit is designed to handle safely.
Current Rating: The maximum continuous current the termination unit can carry.
Wire Gauge Range: The range of wire sizes (AWG or metric) that can be securely terminated.
Number of Poles/Terminals: The number of individual connection points.
Connection Method: Screw clamp torque specifications, spring force, or push-in retention force.
Insulation Material: The type of plastic or other insulating material used (e.g., polyamide, polycarbonate).
Flammability Rating: UL or other standards indicating the material's resistance to burning.
Operating Temperature: The range of ambient temperatures the unit can operate within.
Mounting Type: DIN rail standards (e.g., TS35), panel mounting dimensions and hole patterns.
Dimensions: Physical size of the termination unit (length, width, height).
Certifications: UL, CSA, CE, and other relevant industry certifications.

Product Advantages

Organized Wiring: Provides a neat and structured way to manage electrical connections.
Safety: Reduces the risk of accidental contact with live wires, especially with touch-safe designs.
Reliable Connections: Ensures secure and consistent electrical contact, minimizing failures.
Ease of Installation and Maintenance: Simplifies wiring and allows for easier troubleshooting and component replacement.
Flexibility: A wide variety of types and configurations to suit diverse application needs.
Space Savings: Compact designs can help optimize space within enclosures.
Modularity: Many terminal block systems allow for easy expansion and customization.
Protection: Some units offer integrated protection features like fusing or surge suppression.

Important Considerations

Application Requirements: Carefully select the termination unit based on the voltage, current, wire size, and environmental conditions of the application.
Wiring Standards: Adhere to relevant electrical wiring codes and standards during installation.
Torque Specifications: For screw-type terminals, use the manufacturer's recommended torque to ensure a secure connection without damaging the wires or terminals.
Wire Preparation: Properly strip wires to the correct length to ensure proper contact within the termination unit.
Environmental Conditions: Consider temperature, humidity, and potential exposure to dust or chemicals when selecting the appropriate IP rating or material.
Labeling: Clearly label all terminations for easy identification and maintenance.
Compatibility: Ensure the termination unit is compatible with the type and size of wires being used.
Safety Regulations: Follow all relevant safety regulations during installation and operation.

Product Applications

Industrial Control Panels: Connecting field devices (sensors, actuators) to PLCs and other control equipment.
Power Distribution: Distributing electrical power within machinery and enclosures.
Building Automation: Connecting HVAC controls, lighting systems, and security devices.
Transportation: Wiring in vehicles, trains, and aircraft.
Machinery and Equipment: Providing connection points for motors, switches, and other electrical components.
Renewable Energy Systems: Connecting solar panels, inverters, and batteries.
Telecommunications: Providing termination points for communication cables.
Test and Measurement Equipment: Creating organized and accessible connection points for signals.

EHD2100225A EATON

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
