EBMBBTT100TED36 EATON

EBMBBTT100TED36 EATON Analog Output Modules

Brand：EATON Model number：EBMBBTT100TED36

Country of origin: the States Product weight：0.55kg

HS code：8538900000

Product Details：

Product Dimensions：

EATON's analog output modules are designed to provide precise and reliable control of various industrial devices. These modules convert digital signals from a control system (such as a PLC) into analog signals, which can then be used to control actuators, valves, drives, and other analog-controlled equipment.

Key Product Details:

Functionality:

Conversion of digital signals to analog voltage or current signals.
Control of analog devices in industrial automation systems.

Typical Output Ranges:

Voltage outputs: 0-10V, +/-10V, 0-5V, etc.
Current outputs: 4-20mA, 0-20mA.

Applications:

Process control (e.g., controlling valve positions).
Drive control (e.g., setting motor speeds).
Temperature control.
General industrial automation.

Product Parameters:

Number of Channels: Varies depending on the specific module.
Resolution: Determines the precision of the analog output.
Accuracy: Indicates the deviation of the actual output from the desired output.
Output Range: The range of voltage or current that the module can produce.
Response Time: The time it takes for the module to change its output in response to a digital input.
Isolation: Electrical isolation between channels and between the module and the system.
Power Supply: Voltage and current requirements.
Operating Temperature: The range of temperatures in which the module can operate.

Product Advantages:

High Precision: EATON modules are designed for accurate and stable analog output.
Reliability: Robust design for industrial environments.
Flexibility: Wide range of output options to suit various applications.
Integration: Seamless integration with EATON's control systems.
Diagnostic Capabilities: many of the modules have diagnostic capabilities that can help to locate and solve problems.

Important Considerations:

Wiring: Proper wiring is essential for accurate and reliable operation. Use shielded cables to minimize noise.
Calibration: Regular calibration may be required to maintain accuracy.
Environmental Conditions: Ensure that the module is installed in an environment that meets its operating temperature and humidity requirements.
Power Supply: Provide a stable and reliable power supply to the module.
Signal Integrity: Maintain signal integrity by minimizing cable lengths and avoiding sources of electrical noise.
Safety: Always follow safety guidelines when working with electrical equipment.

Product Applications:

Industrial automation systems
Process control applications
Manufacturing plants
Building automation
Energy management systems.
