69-202 EATON

69-202 EATON Filter Modules

Brand：EATON Model number：69-202

Country of origin: the States Product weight：0.55kg

HS code：8538900000

Product Details：

Product Dimensions：

Eaton offers a comprehensive range of filter modules designed for various industrial and commercial applications. These modules are crucial for removing contaminants from liquids and gases, ensuring the purity of the process fluids, protecting downstream equipment, and meeting specific quality standards.

Product Details

Functionality:

Eaton filter modules are designed to remove particulate matter, sediment, and other impurities from liquids or gases.
They utilize various filtration media and technologies to achieve the desired level of cleanliness.
The modular design allows for easy integration into existing systems and facilitates maintenance and replacement.

Types:

Filter Bags and Housings: Versatile for various liquid filtration applications, offering different bag materials and micron ratings.
Filter Cartridges and Housings: Available in various materials and designs (e.g., pleated, depth, membrane) for precise filtration.
Automatic Backwashing Filters: For continuous filtration with automated cleaning cycles, reducing manual intervention.
Strainers: For removing larger particles and debris, often used as pre-filters.
Specialty Filters: Designed for specific applications like oil and gas, chemical processing, and water treatment.
Eaton provides a wide array of filter modules, including:

Key Features:

Robust construction for industrial environments.
Wide range of filtration media and micron ratings available.
Modular design for scalability and ease of maintenance.
Compatibility with various process fluids and gases.
Options for different pressure and temperature ratings.
Compliance with industry standards and certifications.

Product Parameters

Filtration Media:

Materials such as polypropylene, nylon, polyester, cellulose, stainless steel mesh, and various specialty media.

Micron Rating:

The size of particles the filter can effectively remove, ranging from sub-micron to hundreds of microns.

Flow Rate:

The volume of fluid or gas that can pass through the filter module per unit of time at a given pressure drop.

Pressure Rating:

The maximum operating pressure the filter module can withstand.

Temperature Rating:

The range of temperatures the filter module can operate within.

Housing Material:

Materials such as carbon steel, stainless steel, and engineered plastics, depending on the application and fluid compatibility.

Connection Types:

Flanged, threaded, or other connection types to integrate with the system piping.

Sealing Materials:

Various elastomers like Nitrile, EPDM, and Viton, compatible with the process fluid.

Product Advantages

Reliable Performance:

Eaton filter modules provide consistent and efficient removal of contaminants.

Equipment Protection:

Protect downstream equipment from damage and fouling, extending their lifespan.

Improved Product Quality:

Ensure the purity and quality of the final product by removing unwanted particles.

Reduced Maintenance Costs:

Efficient filtration can reduce the frequency of cleaning and maintenance of downstream equipment.

Versatility:

A wide range of filter types and media allows for customization to specific application needs.

Ease of Use:

Modular designs often simplify installation, maintenance, and filter element replacement.

Scalability:

Modular systems can be easily expanded or modified to accommodate changing process requirements.

Important Considerations

Application Requirements:

Thoroughly analyze the fluid or gas to be filtered, the type and size of contaminants, the desired level of cleanliness, flow rate, pressure, and temperature.

Media Compatibility:

Ensure the filter media and housing materials are chemically compatible with the process fluid or gas.

Micron Rating Selection:

Choose the appropriate micron rating to achieve the required level of filtration efficiency without causing excessive pressure drop.

Pressure Drop:

Consider the pressure drop across the filter module at the design flow rate, as this affects the overall system efficiency.

Maintenance Schedule:

Establish a regular maintenance schedule for filter element replacement or cleaning to ensure optimal performance.

Disposal of Filter Elements:

Follow proper disposal procedures for used filter elements, considering any potential hazardous materials.

System Integration:

Ensure the filter module is properly sized and integrated into the overall system design.

Product Applications

Industrial Processing:

Filtration of process water, chemicals, solvents, and coatings.
Removal of catalysts, adsorbents, and other solids.

Food and Beverage:

Clarification of liquids like juices, beverages, and edible oils.
Removal of yeast, bacteria, and other microorganisms.

Pharmaceuticals:

Sterile filtration of drug products and intermediates.
Removal of pyrogens and particulate matter.

Oil and Gas:

Filtration of produced water, injection water, and process streams.
Protection of pumps, compressors, and other critical equipment.

Water Treatment:

Pre-filtration for reverse osmosis (RO) and other membrane systems.
Removal of sediment, turbidity, and microorganisms.

Power Generation:

Filtration of cooling water, fuel oil, and lubricating oil.

Automotive:

Filtration of paints, coatings, and process fluids.

69-202 EATON

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
