123AL02389A EATON

123AL02389A EATON analog module

Brand：EATON Model number：123AL02389A

Country of origin: the States Product weight：0.55kg

HS code：8538900000

Product Details：

Product Dimensions：

Eaton analog modules are crucial components in industrial automation systems, designed to interface with analog signals from sensors and control analog output devices. These modules facilitate precise measurement and control of continuous variables like temperature, pressure, flow, and voltage.

Product Details

Functionality:

Analog input modules convert analog signals from field devices (e.g., temperature sensors, pressure transducers) into digital values that a control system can process.
Analog output modules convert digital values from the control system into analog signals that can control actuators (e.g., valves, drives).

Types:

Analog input modules (voltage, current, thermocouple, RTD).
Analog output modules (voltage, current).
Combination analog I/O modules.
Eaton offers a variety of analog modules, including:

Key Features:

High-resolution analog-to-digital (A/D) and digital-to-analog (D/A) conversion.
Galvanic isolation to protect the control system from electrical noise.
Various signal ranges and types to accommodate diverse sensor and actuator requirements.
Diagnostic capabilities for troubleshooting.
Compatibility with various industrial communication protocols.

Product Parameters

Input/Output Ranges:

Voltage (e.g., 0-10V, ±10V).
Current (e.g., 4-20mA, 0-20mA).
Temperature (thermocouple types, RTD types).

Resolution:

A/D and D/A conversion resolution (e.g., 12-bit, 16-bit).

Accuracy:

The precision of the analog signal conversion.

Isolation Voltage:

The voltage rating for galvanic isolation.

Communication Interface:

Ethernet/IP, Modbus TCP, Profibus, etc.

Operating Temperature:

The range of temperatures the module can operate within.

Product Advantages

Precise Control:

Enable accurate control of analog processes.

Reliable Measurement:

Provide reliable and accurate analog signal measurement.

Noise Immunity:

Galvanic isolation protects against electrical noise.

Flexibility:

Wide range of signal types and ranges to suit various applications.

Diagnostic Features:

Facilitate troubleshooting and maintenance.

Important Considerations

Signal Type and Range:

Ensure the module is compatible with the sensor and actuator signal types and ranges.

Resolution and Accuracy:

Select modules with appropriate resolution and accuracy for the application.

Isolation:

Consider the need for galvanic isolation in noisy environments.

Wiring and Installation:

Follow proper wiring and installation procedures.

Environmental Conditions:

Ensure the module can withstand the operating environment.

Product Applications

Process Control:

Chemical, pharmaceutical, and food and beverage industries.

HVAC Systems:

Temperature and humidity control.

Manufacturing:

Controlling motor speeds, valve positions, and other analog processes.

Energy Management:

Monitoring and controlling energy consumption.

Water Treatment:

Monitoring and controlling water pressure, flow, and level.

02-396739 EATON

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
