1756-IR6 Allen-Bradley ControlLogix 6 Pt Isolated RTD Module

Product Details：

1756-IR6 Allen-Bradley ControlLogix 6 Pt Isolated RTD Module

Brand：Allen-Bradley Model number：1756-IR6

Country of origin: United States Product weight：0.39kg

HS code：8517623990

Product Dimensions：

This manual describes how to migrate from 1756, 6-channel isolated analog I/O modules to their newer 8-channel isolated counter parts in the 1756 analog I/O platform.

Throughout the product lifecycle, as products mature, Rockwell Automation will be there as your partner to help you get the most out of your current equipment, to help you determine your next steps, and to help you lay out a plan for the transition to newer technology.

Whether you choose to migrate all at once or use our unique, phased approach to help minimize the costs, risks, and complexities involved with managing legacy products and systems, Rockwell Automation has the tools and the experience to guide you through the transition.

For more information, see Migration Solutions Brochure, publication

MIGRAT-BR002.

While this document covers the ease of replacement from a 6- to 8- channel module from a programming standpoint a user must still make changes to the physical system due to differences across all modules RTBs.

The 8-channel modules that are discussed in the manual refer to any 8-channel module at firmware revision 2.011 or later. Firmware revision 2.011 and later supports Emulation mode. This mode allows an 8-channel module to be configured, return input data and accept output data that acts as if it were a 6-channel module.

In Emulation mode, when a forward open containing configuration data is sent to the 8-channel module it can accept it and respond as if it were a 6-channel module. After the connection is established, all data (input/output) will be sent to or from the controller in the same format and tag structures as a 6-channel module. You can directly replace a 6-channel module with an 8-channel module with no I/O tree modifications or program changes with this method.

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
