07KT97 GJR5253000R0200 ABB

Product Dimensions：

The basic unit 07 KT 97 R100 is the standard device for all applications. In addition, there are basic units with reduced

performance (e.g. 07 KT 95 or 07 KT 96) as well as ones with extended performance (e.g. 07 KT 97 R160 with

ARCNET connection, 07 KT 97 R0120 with PROFIBUS connection and 07 KT 97 R0162 with both ARCNET and

PROFIBUS connection). A comparison table is given on the next page. This document describes the basic unit 07 KT 97

R100 and then adds the data sheets of the other devices which only show the differences.

The following has to be observed for project planning and

start-up:

· Programming

is performed with AC31 programming software, which

can be run on commercially available IBM compatible

PCs (see documentation of the programming system

907 AC 1131).

· Online program modification

A quick modification of the user program is possible

without interrupting the operation (see programming

system 907 AC 1131).

· Possible operating modes

– Stand-alone basic unit

– Bus master basic unit

– Slave basic unit

· Backup of data areas,

i.e. saving of data during power OFF/ON, is possible

with an integrated battery and/or

by storing them in the Flash EPROM.

The technical specifications of the inputs are the same

with the other digital inputs, but with the following

exception:

Caused by the direct electrical connection with the

output, the varistor for demagnetization of inductive

loads (see figure above) is also in effect at the input.

Therefore, the voltage difference between UP5 and

the input signal must not be greater than the limit voltage of the varistor.

The limit voltage of the varistor is ca. 36 V. This means,

that if UP5 = 24 V, the input signal voltage must be

between -12 V and +30 V. If UP5 = 30 V, the input

voltage has to be within -6 V and +30 V.
